IDC terminal crimping machine, flat ribbon cable IDC crimping machine

Application:

This is an semi-automatic IDC crimping machine. It works for different types of flat ribbon cable. No need to change applicator, fixing jig is customized. It can work for various IDC/IDE terminals.

We have machines for max 40P and 50P.

Note: If connectors are same pitch , different Pins can can use same fixture. It is adjutable. For example, 2.54 pitch , 2P-40P can all use same fixture.

Features

1. For 8P-40P IDC flat wire crimping head machine instead of hand pressure pliers, the extrusion efficiency is high quality and stable and the operation is simple.

2.Less gas consumption, low failure rate, easy maintenance.

3. Used with bakelite base, simple operation, wear resistance and high precision.

4. Suitable for crimping cable of IDC products.

5. After the product is pushed in, it will be automatically stamped, and the cylinder will be reset after completion. The operation is simple and easy to learn.

6. It can be pressed 300 ~ 600 times per hour according to the product type.

7. Using 6 ~ 8kg air pressure, 220V power supply.

8. The body is made of steel, which is stable and durable. The exterior is chrome-plated, beautiful and not rusty.

Pramater:

Model: RS-IDC40

Power Supply:220V

Weight:14KG

Size: 250X 200 X330mm

For max 40Pins
